SMT as the core process of modern electronic manufacturing, has a direct impact on the performance and reliability of the entire product. Therefore, it is crucial to establish a comprehensive SMT inspection standard. Next, Hunan Charmhigh Electromechanical, a professional SMT placement machine manufacturer, will discuss the SMT inspection standard with you.

Firstly, visual inspection is the first step in SMT inspection. The welding surface should be clean and free of stains, with full and bright solder joints, and no defects such as dry joints or cold solder joints. At the same time, the components should be flatly mounted without inclination or tilting, and the board markings should be clear and accurate. These visual requirements, although seemingly simple, directly reflect the fineness of the welding process.

Secondly, the standards for dimensions and positions are also crucial. The dimensions of components should meet the requirements of the specification sheet, and the positional deviation should be within the allowed tolerance range. The alignment between the solder pad and the component pins should also be accurate. Strict adherence to these standards helps ensure the electrical performance and mechanical strength of the circuit board.

Moreover, the assessment of welding quality is equally important. The solder joints should have good electrical conductivity and mechanical strength, with no cracks or pores. The welding temperature and time should be controlled within the process requirements to avoid over-burning or insufficient welding. These assessment indicators directly reflect the stability and reliability of the welding process.

Component matching is also an aspect that needs to be paid attention to during the inspection process. The components used should be consistent with the models and specifications in the BOM, with no mixing or misplacement of materials. Additionally, the batch number, production date, and other information of the components should meet the relevant quality requirements.

Electrical performance testing and functional verification procedures are the key links in inspecting welding quality. Through open/short circuit testing, critical electrical parameter testing, and functional testing, the performance of the circuit board can be comprehensively evaluated to ensure it meets the design requirements.

Lastly, reliability testing methods are also indispensable. Through temperature cycling tests, vibration or shock tests, and other means, the working conditions of the circuit board under different environments can be simulated to test its stability and reliability.

In summary, the SMT inspection standard covers multiple aspects ranging from appearance to performance, and from dimensions to reliability. Relevant departments and personnel should strictly follow this standard in their inspection work to ensure that the SMT welding quality meets product requirements, providing strong support for the performance and reliability of the product.
